Collecting Juniper RSI and Log Files for JTAC

We run through how to collect RSI logs for Juniper JTAC support and how to archive your log files.

Collecting Juniper RSI and Log Files for JTAC

During your time as a network engineer, you may be required to collect log files and RSI info to assist JTAC with investigations.

RSI Collection

request support information | save /var/tmp/rsi_DEVICE_NAME_OR_DATE.txt

Save to a directory of your choice, but I prefer /tmp due to ease of location when transferring the files off.

This process may hang for a bit, but don’t panic; this is normal. Depending on the device, this process can take up to 5 minutes but doesn’t affect traffic or the device.

Log File Collection

file archive compress source /var/log/* destination /var/tmp/logs_DEVICE_NAME_OR_DATE

This command compresses the logs directory into a single file and saves the file to the /var/tmp directory.

Transfer them out!

That’s it. Once complete, you can transfer the files from the device over to your machine (with FTP/ SFTP or whatever suits you) in readiness to be sent to your support provider/ JTAC.

A recommended piece of software to use is WinSCP, a free to use (and essential) toolkit to obtain the logs from your device. Simply set the remote location to /var/tmp and login with your usual credentials and pull the files from the device.
